RemoteXPC: Wireless iOS Testing With Appium [Testμ 2026]

The iOS 17 Breaking Change

Apple announced iOS 17 in June 2023 and shipped device services behind CoreXPC and RemoteXPC.

By that September the existing service paths had stopped working. Appium’s iOS tests began failing because the underlying service protocol had switched entirely, and the tunnel became mandatory.

Swastik Baranwal placed a further tightening around March 2024, roughly two years before the workshop, and said the team spent about a year debugging before the project started.

The stack that broke had worked for almost a decade, which is why the breakage was so disruptive across the ecosystem.

Roughly a year after the break, the team started building a JavaScript client for the Appium ecosystem, which became appium-ios-remotexpc.

The Pre-iOS 17 Toolchain

Before iOS 17, an automation host needed a stack of tools at once: Appium, Xcode, libimobiledevice and similar utilities.

usbmuxd carried the connection, and USB was the only transport. One cable per device gave one trusted path, every single time.

lockdown was the gateway connecting iOS services on the phone to the Mac, mapping each service to a port on the host.

Navin Chandra used Apple File Conduit as the example: the files push-and-pull service gets a unique port, and that port changes every run.

Services in that era included installation, logs, WebDriverAgent and AFC.

Inside appium-ios-remotexpc

The library implements Apple’s RemoteXPC protocol in Node.js for iOS 17 and above, released under Apache 2.0 and hosted in the Appium GitHub organisation.

It pairs with iOS devices, builds secure tunnels and exposes around 20+ device services, including screenshots, application diagnostics and file transfer, over Wi-Fi and over USB.

It is not wireless-only. The presenters stressed that plugging in a USB cable and using RemoteXPC works identically, since both paths use the same protocol, and Wi-Fi just adds some configuration steps.

It sits underneath the Appium XCUITest Driver, which previously used appium-ios-device as the protocol and now auto-switches to the RemoteXPC tunnel, leaving test scripts unchanged.

The whole stack rests on iOS TunTap, which Swastik Baranwal called the foundation without which the project would not have been possible.

Device Lab and Host Costs

Labs start at five devices or so and grow with customer demand. Every added device means another cable and another hub port, hubs saturate, and ports run out. Cabling does not scale with the lab.

USB cables wear out and devices drop mid-run, with no way to tell which device died short of physically walking the rack.

Every rack also needs a macOS host, whether a Mac mini, a MacBook or rented Mac capacity, because iPhones would not connect to Linux or Windows. That is pure added cost with no way to reduce it.

Observability is the quiet casualty. When a session dies mid-run you get little to no logs, because the USB link that would have relayed crash logs and diagnostics is exactly what disconnected.

Pairing and Tunnel Mechanics

The first connection is over USB. Plug in, accept the Trust This Computer prompt on the phone, enter the passcode, and a pair record is stored on the host. The prompt never appears again for that device and host.

Navin Chandra framed the USB-first pairing as an unavoidable Apple security requirement. Without it, anyone could connect to and run automation commands on every iOS device on a Wi-Fi network.

In Finder you must tick “Show this iPhone when on Wi-Fi” before any wireless tunnel will work.

The tunnel path runs like this: usbmuxd and lockdown find the paired device, CoreDeviceProxy hands back a TLS socket, a virtual interface is created on the host, and an IPv6 tunnel carries the RSD-discovered services covering diagnostics, logs, files and the rest.

There is one tunnel per device. With 15 to 20 devices or more, you start a tunnel per device and pass a UDID to target a specific one.

Creating a network interface is a kernel operation, so the tunnel needs sudo or admin rights. TunTap is built into macOS, works similarly on Linux, and Windows uses a different protocol underneath.

Demo: Cutting the Cable

Prerequisites were walked through live: clone the sample repo and run npm install, which pulls appium-ios-remotexpc and iOS TunTap, then Node up to version 24 with nvm suggested for switching, a real iPhone or iPad on iOS 18 or above, a USB cable, sudo access, and device and host on the same SSID. That Node and iOS version guidance will age.

The sample repo is Apache 2.0 licensed with independently executable .mjs examples, runnable through node <file> or npm run scripts.

The repo’s start-tunnel script wraps the tunnel creation script bundled with appium-ios-remotexpc, so every RemoteXPC tunnel flag works, including a reconnect flag shown set to 2 to retry twice at one-second intervals if the device drops.

The live sequence on a MacBook: iPhone plugged in and charging, trust accepted, tunnel started over USB, tunnel closed, cable physically unplugged on camera, tunnel re-run with no cable attached, and it still started.

The device listing then showed a network connection entry alongside the same device ID that had previously shown only USB. The tunnel came up on port 4231, and the service list included the newer CoreDevice services.

Wireless Troubleshooting

The common causes they gave: device and host not on the same Wi-Fi; the iOS device asleep or locked, when it must be awake and unlocked; the “show this device when on Wi-Fi” box not ticked in Finder or in the Apple Devices app on Windows and Linux; or the USB cable still plugged in.

That last one catches people because it looks like success. When both USB and network connection types are present, RemoteXPC is deliberately coded to prefer the USB path, so you have to unplug to actually exercise the wireless route.

The repo ships a cross-platform npm run net check script that runs a query between the iOS device and the host and reports which condition is failing.

Toggling Wi-Fi or holding a dynamic IP can rotate the host’s address and invalidate the existing pair record. On macOS a copy-paste command restarts networking; on Windows you restart the Apple Devices app and set the network profile to Private rather than Public.

The 20+ Device Services

Location simulation and the condition inducer are DVT instruments. You start the DVT service over RemoteXPC first, then call the instrument, for example set() with a latitude and longitude.

One gotcha is worth writing down. CoreDevice services such as pasteboard do not appear at all if an older developer disk image is mounted, and the library ships an image mounter service so you can mount the current DDI without opening Xcode.

Navin Chandra noted the condition inducer throws an outright error on the older appium-ios-device path because Apple dropped support for it, which makes RemoteXPC effectively mandatory for that service. The iOS version where that support ended is not intelligible in the captions.

Zip Conduit was described as the newer, faster route for installing signed .ipa files, without a benchmark or figure attached to the comparison.

Live Service Demos

Location. Example 07 started the DVT service with the device UDID and set latitude and longitude to Apple Park in California. Maps visibly jumped on the phone, held for 10 seconds, then the console confirmed the real GPS location had been restored. No jailbreak involved.

Screenshot. The example resolved the UDID, started the developer service, requested the image asynchronously, checked the PNG header for validity, created the artifacts directory recursively and wrote a date-stamped file. The captured Maps screen was displayed live.

Battery. Example 04 queried IOPMPowerSource and printed battery installed, a current capacity of 2153, external connected as false because the cable was out, a temperature of 34°C and a cycle count of 506, with a cycle defined as 0 to 100 and back to zero. Swastik Baranwal said on air that the capacity figure looked wrong to him.

Apps. Example 06 listed installed apps with bundle ID, bundle and display name and short version, split system apps from user-installed ones, found Settings via the preferences bundle ID, killed any existing instance and relaunched it through the process control service, printing the PID. Settings visibly opened on the phone.

Pasteboard and rotation. Example 15 read the clipboard, set a new time-stamped string verified by pasting on the device, then rotated the screen left. Settings refused to rotate so they switched to Safari, which rotated and reset after two to three seconds. Screen rotation lock has to be off.

Only the tunnel host needs sudo. None of the service examples required it.

Apple TV and Windows Hosts

Apple TV is supported over Wi-Fi with no USB port at all, through discovery, PIN pairing and tunnelling, all public API, using the same underlying TunTap connection as iOS devices. No demo was run, because connecting takes too long for a live session.

The Windows path starts with the Apple Devices app from the Microsoft Store, which is required because the trust dialog does not appear automatically on Windows or Linux. Then plug in once, trust and enter the passcode, tick “Show this iPhone when on Wi-Fi”, and start the tunnel. All services and APIs are identical to macOS.

The live Windows run was not frictionless, which makes it more useful. The first plug-in was not recognised and the cable had to be re-seated. The tunnel over USB then listed two entries, USB and network, for the same device, the tunnel was closed, the cable unplugged, and it restarted network-only from Windows.

From the Windows host they re-ran the location simulation example, which errored with “no device found” once until Enter was pressed at a stuck tunnel prompt, and it set Apple Park for 10 seconds. The battery example then returned the same results as on macOS.

Windows also needs elevated rights, and the presenters noted Windows now ships a sudo that can be activated from settings and works as a symlink for administrator.

XCUITest Driver Integration

Appium test code is unchanged. The presenters repeated that whatever you wrote before still works, and what changed is inside the driver.

The XCUITest Driver adds a condition checking whether the device is on iOS 17 or above and, if so, routes through the RemoteXPC protocol this project implements.

Under the hood it uses appium-ios-remotexpc for the tunnel, testmanagerd and XCTest device work, so the driver operates wired or wirelessly.

For iOS 17 and above you need no Xcode and nothing else, just the XCUITest Driver.

If you have not started a tunnel, the driver emits a warning that you are on iOS 18 or above and need an active tunnel for the advanced features, so scripts stay healthy rather than failing obscurely.

Limitations and Takeaways

The minimum is iOS 17.4, because RemoteXPC arrived from 17.4 onwards, with iOS 18 or above recommended. The presenters also named newer releases and a beta as supported, which covers software that cannot be verified from the session.

The first pair must happen over USB and cannot be skipped, as an Apple security requirement.

sudo or Windows admin is needed once for the tunnel, because it creates a kernel-space network interface. Individual service commands need no elevation.

A locked device blocks services such as installation proxy, AFC and provisioning profiles, which return a warning telling you the device must be unlocked. Swastik Baranwal recommended disabling auto-lock on lab devices.

Wi-Fi quality matters. An AFC push or pull of roughly a 200 MB file needs a good link, and they recommended a 5 GHz network.

The closing takeaways: one USB pairing and then everything, logs included, over Wi-Fi; no Xcode anywhere in any example; the tunnel registry API; and Windows and Linux hosts breaking the Mac-per-rack model. The workshop demonstrated one device at a time on macOS and one on Windows, so larger wireless racks remain the goal rather than something shown on stage.

Q & A Session

The host’s audio failed during the Q&A, so Navin Chandra read the questions out from the chat and answered them.

• If we disconnect a wirelessly connected iPhone and then reconnect it while RemoteXPC is running, is the device remembered, or do we redo the plug-in and trust process?

  Navin Chandra: The USB cable and the trust dialog are needed only the very first time a given device meets a given host, whether Mac, Windows or Linux. Accepting the prompt and entering the passcode stores a pair record on that host, so pairing from Windows writes it on the Windows machine and pairing from macOS writes it on the Mac. After that you never repeat the trust or the pairing for that device and host combination, and if the wirelessly connected iPhone drops, the reconnection happens entirely over Wi-Fi.

• Is it possible to collect iPhone performance metrics remotely, such as CPU usage?

  Navin Chandra: Yes, through the diagnostics service the workshop had just demonstrated. The battery example is one instance of it, with level, capacity, charging state, temperature and cycle count all coming back over the wireless tunnel. For CPU you use the other diagnostic parameters, or the process control service, which can report how much CPU a specific process is using. He did not run a CPU demo, so battery stayed the only diagnostics output actually shown.

• How does RemoteXPC handle packet fragmentation and flow control when multiplexing multiple virtual channels over a single wireless tunnel?

  Navin Chandra: The premise of a single shared tunnel does not apply, because RemoteXPC creates a unique tunnel per device rather than multiplexing several devices onto one, which keeps each device’s packets separate as a separation-of-concerns choice. Within a tunnel, fragmentation and flow control are handled by multiplexing algorithms inside the tunnel layer, so users do not manage packet transport themselves. He credited the TunTap library the project depends on with the IPv6 tunnelling and the underlying transport work. No throughput, window size or fragment-limit numbers were given.
